introduction

ALOE's Alorpro and Aloeplus barn ceiling fans deliver powerful airflow ranging from 4,950 to 13,850 m³/min, providing 20–30% wider coverage compared with standard agricultural fans. This high-volume circulation rapidly reduces heat, moisture, and ammonia levels, helping livestock stay healthier and more productive. Even at maximum output, both models maintain low-noise operation (<45 dB) and high energy efficiency, making them ideal for long-hour ventilation in barns.

With their strong performance and durable design, these HVLS fans are not only suitable for livestock barns but also perfect for dairy farms, poultry houses, greenhouses, feed storage areas, and other agricultural spaces requiring stable airflow and effective humidity control.

Model	Size	Motor Power KW	Fan Rotation Range RPM	Max Air Volume M3/Min	Effective coverage area Air speed≥1M/S	Rated Voltage V	Fan Weight KG	Noise Level	Energy Consumption KW·H
Aloeplus7.3	7.3	1.5	10-58	13850	1100	380V/3.3A	127	42	1.5
Aloeplus6.1	6.1	1.5	10-60	12500	1000	380V/2.5A	112	42	1.5

parameter

Model	Size M	Motor Power KW	Fan Rotation Range RPM	Max Air Volume M3/Min	Effective coverage area Air speed≥1M/S	Rated Voltage V	Rated Current A	Fan Weight KG	Noise Level	Energy Consumption KW·H
Aloepro7.3	7.3	1.5	10-60	13650	1000	380/220	3.4	113	40	1.45
Aloepro6.1	6.1	0.8	10-65	11500	900	380/220	2.9	100	40	0.75
Aloepro5.5	5.5	0.8	10-70	10500	800	380/220	2.8	82	40	0.7
Aloepro4.9	4.9	0.8	10-80	9800	700	380/220	2.7	80	40	0.7
Aloepro4.2	4.2	0.4	10-90	8900	550	380/220	2	69	40	0.4
Aloepro3.8	3.8	0.4	10-95	7900	450	380/220	2	67	40	0.4
Aloepro3.3	3.3	0.4	10-100	6950	400	380/220	2	64	40	0.35
Aloepro2.5	2.5	0.3	10-120	4950	300	220	2	53	40	0.3

feature

Strong air volume
60-inch outdoor barn ceiling fans have a maximum air volume of 13,850 m³/min. A single fan can cover a space area with a radius of more than 20 meters, continuously output an effective wind speed of ≥1m/s, and quickly improve the ambient air quality.

High-strength structure

The fan blades are made of 6063-T6 magnesium-aluminum alloy material, with a thickness of 2mm and a width of 180mm. They contain a double-rib reinforcement structure , has strong fatigue resistance and prevents blade breakage during long-term operation.

Stable operation
The 60-inch outdoor barn ceiling fans with PMSM direct-drive motors do not require gearboxes, avoiding mechanical wear and lubrication maintenance. The motor efficiency is 81.5%, the maximum power consumption is only 1.5kWh/h, it supports long-term stable operation, and the motor life is more than 10 years.

Safety reinforcement
The fan blade connector uses 15mm thick 45 steel, with a force area of 195cm², which effectively disperses the torque and reduces structural wear. The external double clamp structure further enhances the stability and prevents hidden dangers caused by the misoperation of 60-inch outdoor barn ceiling fans.

Simple operation
The 60-inch outdoor barn ceiling fans are equipped with an integrated frequency conversion control system, which integrates the start and stop buttons, stepless speed knob, and operation indicator light. Users can quickly adjust the wind speed through the knob without complicated settings.

FAQ

Q: What is your minimum quantity?

A: Usually, it's 1000m per color, but we can accept orders smaller than 1000m. Discounts are available for orders larger than 6,000 meters, and the best price for orders above 10,000 meters.

Q: What are your payment terms?

A: For payments under $1000 USD, full payment is required in advance. For payments over $1000 USD, a 30% T/T deposit is required in advance, with the balance before shipment.

Q: Is your company a trading company or a manufacturer?

A: We are a manufacturer, PMSM motors and HVLS fans are our products. And motors for large industrial fan are also developed and produced by ourselves. We deal with customers directly and don't have relations with any trader.

Q: Can your company do OEM and ODM?

A: Yes, both OEM and ODM are acceptable. Motor power, fan color, controllers, fan accessories and overall fan style can be customized.

Q: Can we use our own logo?

A: Yes, we can make your logo according to your requirements.

Q: How many kinds of packaging do you have?

A: We currently have 3 kinds of package, including motor, blade and accessory packaging boxes.

Q: Can your company make package as customer's requirement?

A: Yes, you only need to provide the packaging design and we will produce it according to your requirements. We also have professional designers who can help you with packaging design.

Q: How many different types of products does your company produce?

A: Now we have 24 products. We are a professional OEM industrial fan supplier, just give us the actual product or the product you designed, we can manufacture it for you.
