introduction
Hotel Ceiling Fans are ceiling fans specially designed for hotel places, which are both practical and decorative. Some ceiling fans are equipped with lamps and remote control functions, realizing lighting and air supply in one, which is easy to operate and energy-saving. They have various design styles and can be matched with different hotel decoration styles, such as modern simplicity, European retro, Chinese elegance, etc.
|
Model |
Size |
Motor Power |
Fan Rotation Range |
Max Air Volume |
Effective coverage area |
Rated Voltage |
Rated Current |
Fan Weight |
Noise Level |
Energy Consumption |
|
Aloemax4.2 |
4.2 |
0.4 |
10-75 |
9000 |
550 |
380/220 |
2.0 |
68 |
40 |
0.4 |
|
Aloemax3.8 |
3.8 |
0.4 |
10-85 |
8000 |
450 |
380/220 |
2.0 |
65 |
40 |
0.4 |
|
Aloemax3.3 |
3.3 |
0.4 |
10-95 |
7000 |
400 |
380/220 |
2.0 |
60 |
40 |
0.35 |
|
Aloemax2.5 |
2.5 |
0.3 |
10-100 |
5000 |
300 |
220 |
2.0 |
55 |
40 |
0.3 |
|
Model |
Size |
Motor Power |
Fan Rotation Range |
Max Air Volume |
Effective coverage area |
Rated Voltage |
Rated Current |
Fan Weight |
Noise Level |
Energy Consumption |
|
Aloepro4.2 |
4.2 |
0.4 |
10-90 |
8900 |
550 |
380/220 |
2 |
69 |
40 |
0.4 |
|
Aloepro3.8 |
3.8 |
0.4 |
10-95 |
7900 |
450 |
380/220 |
2 |
67 |
40 |
0.4 |
|
Aloepro3.3 |
3.3 |
0.4 |
10-100 |
6950 |
400 |
380/220 |
2 |
64 |
40 |
0.35 |
|
Aloepro2.5 |
2.5 |
0.3 |
10-120 |
4950 |
300 |
220 |
2 |
53 |
40 |
0.3 |
advantages
1. PMSM motor (permanent magnet synchronous motor)
High efficiency and energy saving
PMSM motor uses permanent magnet as excitation source. Under the same working conditions, the energy consumption is lower than that of traditional asynchronous motors, which helps to reduce the overall energy consumption in long-term use. It is suitable for large spaces that are sensitive to operating costs, such as hotel lobbies, factory workshops, etc.
Low noise operation
This type of motor has no brushes and slip rings during operation, which reduces the source of mechanical friction and effectively reduces the operating noise. It is suitable for spaces that require a quiet environment, such as guest rooms, conference rooms, etc.
Long life
The motor uses high-performance magnetic steel and high-quality insulation materials, with strong heat resistance and anti-aging ability, which helps to extend the service life of the motor and reduce the frequency of later maintenance and replacement.
Strong stability
The motor is insensitive to load changes and can stably output torque under voltage fluctuations, ensuring continuous and reliable operation of the ceiling fan under different working conditions.
2. Variable frequency speed controller
Multi-speed adjustable wind speed
The variable frequency technology can achieve stepless speed change or set gear adjustment, and the wind speed can be flexibly adjusted according to space requirements to meet the comfort requirements of different usage scenarios.
Intelligent control system
The controller is compatible with multiple control methods such as remote control, wall switch, mobile application (APP), etc., which is convenient for users to operate remotely, and can set timer on and off to improve the convenience of use.
Overload protection design
It has automatic protection functions such as overvoltage, overcurrent, and overheating. It can automatically shut down in the event of electrical failure or abnormal conditions to enhance the safety of the system.
Energy-saving control algorithm
The control system works closely with the PMSM motor to optimize the operating curve, further reducing energy consumption while ensuring air volume output.
3. Fan blades
Lightweight and high-strength materials
The blades are usually made of aviation aluminum alloy or carbon fiber materials, which have good rigidity and strength, and are light in weight, which helps to reduce the burden on the motor and improve overall operating efficiency.
Fluid mechanics design
The blade shape is optimized based on the principle of fluid dynamics, which can reduce air resistance when rotating, improve the uniformity of air supply range and wind speed, and control the operating noise level.
Multiple sizes available
A variety of blade diameters are available according to different usage environments, which can be flexibly applied to spaces of different heights and areas, such as small guest rooms, large banquet halls, etc.
4. Fan blade connector
High-precision connection structure
The blade connection components are precisely machined to ensure a firm connection between the blade and the motor shaft, reducing structural problems caused by looseness during operation.
Anti-seismic design
The buffer design is integrated in the connector structure, which can effectively absorb vibration shock during operation, improve the stability of ceiling fan operation, and extend the service life of components.
Quick installation system
The structural design is easy to install and disassemble, shortens construction time, reduces manpower and time costs during maintenance, and is suitable for rapid deployment of project engineering.
5. External reinforcement clip (external reinforcement)
Structural safety reinforcement
The reinforcement clip is designed to enhance the overall stability of the ceiling fan, especially in high-speed operation or specific building structures, which can effectively avoid displacement or loosening caused by vibration.
Adapt to a variety of installation scenarios
It can be customized according to the actual installation environment (such as concrete ceiling, steel structure frame, etc.) to ensure that the ceiling fan can be reliably fixed under different structures.
Anti-corrosion treatment
The surface of the reinforcement clip is treated with anti-rust coating or galvanizing, which can maintain a long service life in high humidity or dusty environments and reduce maintenance frequency.
