introduction
Flameproof HVLS fans are large industrial ventilation equipment designed for high-risk environments. They use explosion-proof motors, explosion-proof controllers, and other explosion-proof components, and can operate safely in places with flammable and explosive gases or dust.
|
Model |
Size |
Motor Power |
Fan Rotation Range |
Max Air Volume |
Effective coverage area |
Rated Voltage |
Fan Weight |
Noise Level |
Energy Consumption |
|
Aloeplus7.3 |
7.3 |
1.5 |
10-58 |
13850 |
1100 |
380V/3.3A |
127 |
42 |
1.5 |
|
Aloeplus6.1 |
6.1 |
1.5 |
10-60 |
12500 |
1000 |
380V/2.5A |
112 |
42 |
1.5 |
feature
High energy efficiency
Flameproof HVLS fans use permanent magnet synchronous motors and IE2 high-efficiency motors. Permanent magnet synchronous motors provide a stable magnetic field through permanent magnets, reducing current loss in traditional motors, and the power conversion efficiency is as high as 85% or more.
Good explosion-proof performance
The fan is equipped with an explosion-proof motor and controller, which meets strict explosion-proof standards to ensure safe operation in flammable gas or dust environments. It includes multiple protection functions such as overload, overvoltage, and phase loss, which enhances the safety of Flameproof HVLS fans.
Good stability
The fan adopts a reinforced bearing frame, trapezoidal shaft structure, and enlarged oil seal design to enhance the strength of the mechanical structure, effectively disperse the pressure during rotation, and reduce the vibration of the flameproof HVLS fans during operation, thereby avoiding failures caused by long-term operation.
Good ventilation effect
The fan's streamlined blade design and low-speed high-air volume configuration enable the Flameproof HVLS fan to evenly cover an area of 1,200 square meters, optimize airflow, avoid air stagnation, effectively reduce temperature, and improve indoor air quality. It is suitable for large factories and warehouses.
Certification Guarantee
Flameproof HVLS fans have passed multiple international certifications including CCC, CE, etc., and meet strict safety and quality standards at home and abroad.
